2025 CK2620 HST W/ROPS & LDR

Zero Down financing available!

FINANCE FOR $
2025 Kioti CK2620 with Loader
0% financing and aditional cash rebates are available contact for details

• Engine: 24.5 HP Kioti 3-cylinder diesel

• Transmission: 2-range Hydrostatic (HST)

• Drive Type: 4WD

• Front Loader: KL4030 loader with quick-attach bucket

• Loader Lift Capacity: ~1,835 lbs at pivot pin

• Breakout Force (off ground): ~2,600 lbs

• Rear PTO: 540 RPM, Category 1

• Hydraulics: Dual rear remotes available

• Fuel Tank Capacity: 6.6 gallons

• Warranty: 6-year limited powertrain warranty


Features
KIOTI Diesel Engine
The new 24.5 hp (18.2 kW) diesel engine provides powerful performance and improves fuel efficiency while reducing noise levels.
High Capacity Hydraulic Pump
The high capacity, efficient tandem hydraulic pump gives you smoother handling in heavy-duty working conditions and helps to reduce operator fatigue.
Power Steering
Responsive, powerful and comfortable steering reduces operator fatigue. The power steering system is robustly designed for maneuvering in soft soil and for front loader operation.
Deluxe Seat
A fully adjustable suspension seat allows the operator to ride in comfort no matter what the job. A retractable seatbelt is standard on all KIOTI tractors to ensure operator safety.
Rear PTO
Rear PTO is standard and mid PTO is optional. You can select the rear or mid PTO separately or simultaneously.
Single Lever Joystick
The operation of the front end loader is made easier by the use of a single lever joystick. The joystick allows you to perform all loader functions with a single lever. The lever automatically returns to neutral and the loader stops in place when the joystick is released. A float position allows the bucket free flotation over the ground surface.
Foldable ROPS
A fold-down roll bar allows you to move into tight areas quickly and easily.
Simple Maintenance
KIOTI tractors are designed for easy maintenance. Liftable hoods and removable side panels allow convenient access for daily service checks. Maintaining your tractor for long life and high performance has never been easier.
Center Marker
The center marker on the hood assists with maintaining straight rows.
High Ground Clearance
The minimum ground clearance of 13.4 in. makes usage on rocky or uneven terrain simpler.
Illuminated Dashboard
The illuminated dashboard ensures great visibility while working in bright daylight or at night. The operator can check important instrumentation at a glance with an easy-to-see tachometer, hour meter, fuel temperature gauge and battery charge lamp.
3-Point Control Lever
The 3-point control lever allows you to easily raise and lower the lift arms when attaching implements.
9x3 Manual Transmission
Manual transmission models feature 9F/3R speeds with synchronized 2nd and reverse gears making repetitive back and forward operation more efficient.

Power Take-off (pto)

• P T O Power: 19.5 hp (14.5 kW)
• Mid P T O Speeds: 2,000 rpm (optional)
• P T O Type Trans: Live
• Rear P T O Speeds (1st): 540 rpm

Brakes And Clutch

• Brakes: Wet Multi Disc
• Clutch: Dry Dual Stage

Dimensions W/ Ag Tire

• Width: 54.5 in. (1,385 mm)
• Wheelbase: 65.7 in. (1,670 mm)
• Ground Clearance: 13.39 in. (340 mm)
• Height From Top Of R O P S: 92.91 in. (2,360 mm)
• Length W/ 3-point Hitch: 120.87 in. (3,070 mm)
• Rear Tread Ag Tires - Min: 47.04 in. (1,210 mm)
• Front Tread Ag Tires - Min: 48.22 in (1,225 mm)
• Min. Turning Radius W/ Brake: 107.48 in. (2,730 mm)

Hydraulics

• Total Pump Flow: 11.73 gpm (44.4 L/min)

Point Hitch

• Control Type: Position
• Standard Category: Category 1
• Lift Capacity, 24in. Aft Of Hitch: 1,631 lbs. (740 kg)

Weight

• Weight W/ Ag Tires W/ R O P S: 2,635 lbs. (1,195 kg)

Equipment And Panel
Standard Equipment

• Power Steering
• Rear PTO
• Wet Multi Disc Brakes
• Joystick Valve
• Drawbar
• Headlights
• Parking Brake
• PTO Shield

Optional Equipment

• Front Weights
• Mid PTO
• Clevis Type Drawbar
• Side View Mirror (1 ea)
• Dual Remote Hydraulic Valve (Non-Detent)
• Dual Remote Hydraulic Valve (Spring/Detent/Dual Detent)
• Rear Wheel Weight (Ag Tire Only)
• 3rd Function Kit for Front End Loader

Instrument Panel

• Digital Hour Meter
• Coolant Temperature Gauge
• Electrical Tachometer
• Fuel Gauge
• Engine Oil Pressure Light
• High Beam, Emergency Flasher, Direction Indicators
• Glow Plug Light
